Brand Name : | NACYC ENERGY |
Model Number : | MetisPAS III |
Certification : | SGS, ISO, AS NZS1170, Patents |
Price : | Negotiable |
Payment Terms : | T/T |
Supply Ability : | 10 Megawatts per month |
Delivery Time : | Shipped in 15 days after payment |
Key Benefits:
1. All aluminumm design, excellent durability, with light-weighted structure that can save a lot of space.
2. The angle of the rails has been designed to maximum the harveast of solar power according to your local latitude.
3. Designed as a universal racking system, framed modules from all the popular manufactures can be used.
4. There are screw pile foundation and concrete foundation for customers to choose from.
Technical Data:
Application | Ground |
Max. wind speed | 40m/s |
Max. tilt angle | 30 degrees |
Module | Framed |
Orientation | Landscape & portrait |
Foundation | Concrete block or screw pile |
Material | AL6005-T5, SUS304, Q235 |
Warranty | 10 years |
Notes: Max. wind speed is based on best economical concerns
![]() |
